Light shade and intensity controller 12-24V

The controller is designed to change the light intensity and shade of the strip. Changing the shade is possible only with a special strip of two shades of diodes.

With the touch wheel you can choose the desired shade – warm white or cold white. With the help of two buttons, you canincrease/decrease the light intensity.

Controller characteristics:

• Controlled by radio waves;
• Maximum remote operating distance: 20 metres
• Supply voltage 12V/24V DC
• Maximum output power: 144W (12V) / 288W (24V)
• 2 channels;
• Maximum current per channel: 6A;
• The last set program is retained in the memory;
• 3 x AAA batteries are used;
• Pulse dimensions: 11.4 x 5.7 x 2.4cm (length x width x height);
• Controller dimensions: 8.5 x 8 x 3.3cm (length x width x height);
